Stihl RMA 2 RV User Manual

0478-131-9950-A
49
English 11 Checking the Lawn Mower and Battery
► Place the lawn mower on a level surface.
► Activate the blade.
► Move lever (3) to the desired position.
► Pull control bar for self-propulsion (1) fully in the direction
of handlebar (2) and hold so the thumb encloses
handlebar (2).
The lawn mower starts moving.
10.2.2 Deactivating Drive System
► Release the control bar for self-propulsion.
► Wait until the mower comes to a standstill.
► If the mower does not stop: Pull out the activation key,
remove the battery and consult a STIHL specialist dealer
for assistance.
There is a malfunction in the mower.
11.1 Checking the Controls
Lockout button and switch lever for blade drive
► Pull out the activation key.
► Remove the battery.
► Depress the lockout button and release it again.
► Pull the switch lever for blade drive fully in direction of
handle and release it again.
► If the lockout button or switch lever for blade drive is stiff
or does not spring back to the idle position: Do not use
your mower and contact your STIHL servicing dealer for
assistance.
There is a malfunction in the lockout button or switch
lever.
Switch lever for wheel drive
► Pull out the activation key.
► Remove the battery.
► Pull the switch lever for wheel drive fully in direction of
handle and release it again.
► If the switch lever for wheel drive is stiff or does not spring
back to its idle position: Do not use your mower and
contact your STIHL servicing dealer for assistance.
There is a malfunction in the switch lever for wheel drive.
Lever
► Pull out the activation key.
► Remove the battery.
► Move lever to , and then to .
► If the lever moves too freely: Do not use your mower and
contact your STIHL servicing dealer for assistance.
The lever is defective.
Switching on the mower
► Insert the activation key.
► Fit the battery.
► Depress the lockout button with your right hand and hold
it there.
► Pull the switch lever for blade drive fully in direction of the
handle with your left hand and hold it so that your thumb
is wrapped around the handle.
The blade rotates.
► If 3 LEDs flash red: Remove the activation key and
battery, and contact your STIHL servicing dealer for
assistance.
There is a malfunction in the mower.
► Release lockout button and switch lever for blade drive.
The blade stops rotating after a brief delay.
11 Checking the Lawn Mower and Battery

Stihl RMA 2 RV Specifications

General

Type	Walk behind lawn mower
Cutting width	460 mm
Grass catcher	-
Product color	Black, Grey, Orange
Uncertainty K	0.7 m/s²
Ergonomic handle	Yes
Number of wheels	4 wheel(s)
Rotational speed	3150 RPM
Maximum lawn area	510 m²
Sound power level	88 dB
Handle(s) features	Adjustable, Ergonomic, Foldable, Soft grip
Standard deviation	2 dB
Vibration emission	1.4 m/s²
Sound pressure level	86 dB
Front wheels diameter	200 mm
Maximum cutting height	85 mm
Minimum cutting height	25 mm
Suitable for slope up to	14 °
Power source	Battery
Battery voltage	36 V

Weight and Dimensions

Depth	1420 mm
Width	500 mm
Height	1060 mm
Weight	23000 g
