Stihl RMA 2 RV User Manual

0478-131-9950-A
58
English 19 Troubleshooting
The battery service life has
been exceeded.
► Replace the battery.
The area around the blade
is blocked.
► Clean the lawn mower.
The blade is blunt or worn. ► Sharpen and balance the blade.
The resistance at the blade
is too great.
► If working with self-propulsion engaged: switch off
self-propulsion.
► If working with self-propulsion disengaged: go
forwards slower.
► Set a higher cutting height.
► Mow shorter grass.
The battery gets
stuck when fitting it
into the battery
compartment.
The guides or electric
contacts in the battery
compartment are dirty.
► Clean the lawn mower.
Charging fails to start
after fitting the
battery into the
charger.
1 LED illuminates
red.
The battery is too warm or
too cold.
► Leave the battery inserted in the charger.
Charging starts automatically as soon as the
permissible temperature range is reached.
The grass has not
been cut cleanly or
the lawn is yellow.
The blade is blunt or worn. ► Sharpen and balance the blade.
The resistance at the blade
is too great.
► If working with self-propulsion engaged: switch off
self-propulsion.
► If working with self-propulsion disengaged: go
forwards slower.
► Set a higher cutting height.
► Mow shorter grass.
Fault LEDs on the
battery
Cause Remedy

Stihl RMA 2 RV Specifications

General

Type	Walk behind lawn mower
Cutting width	460 mm
Grass catcher	-
Product color	Black, Grey, Orange
Uncertainty K	0.7 m/s²
Ergonomic handle	Yes
Number of wheels	4 wheel(s)
Rotational speed	3150 RPM
Maximum lawn area	510 m²
Sound power level	88 dB
Handle(s) features	Adjustable, Ergonomic, Foldable, Soft grip
Standard deviation	2 dB
Vibration emission	1.4 m/s²
Sound pressure level	86 dB
Front wheels diameter	200 mm
Maximum cutting height	85 mm
Minimum cutting height	25 mm
Suitable for slope up to	14 °
Power source	Battery
Battery voltage	36 V

Weight and Dimensions

Depth	1420 mm
Width	500 mm
Height	1060 mm
Weight	23000 g
