Stihl RMA 765 V User Manual

0478-131-9838-A
5
English 4 Safety Precautions
4.1 Warning Symbols
The warning symbols on the lawn mower have the following
meaning:
4.2 Intended Use
The STIHL RMA 765 V lawn mower is used to mow grass.
The lawn mower is supplied with energy by a STIHL AR L
battery or a STIHL AP battery together with the ADA 700
double-battery compartment.
Engage self-propulsion.
The lever locks the front wheels in this position.
The front wheels are freely movable when the lever is
in this position.
The cutting height of the front wheels can be set when
the lever is in this position.
The grass catcher bag is being filled.
The grass catcher box is full. Empty the
grass catcher box.
4 Safety Precautions
Follow the safety instructions and their
measures.
Read, understand and keep the instruction
manual.
Wear safety glasses.
Observe the safety instructions on high-velocity
objects and their measures.
Do not touch a turning blade.
Remove the battery during work stoppages,
transport, storage, maintenance or repair.
Pull out the activation key during work
stoppages, transport, storage, maintenance or
repair.
Maintain a safety distance.
Protect the lawn mower from rain and moisture.
Do not immerse in liquids.

Stihl RMA 765 V Specifications

General

Cutting width	630 mm
Grass catcher	Yes
Product color	Black, Grey, Orange
Uncertainty K	0.7 m/s²
Housing material	Aluminium, Plastic
Number of wheels	4 wheel(s)
Rotational speed	3300 RPM
Maximum lawn area	- m²
Mulching function	-
Sound power level	93 dB
Handle(s) features	Adjustable, Foldable
Vibration emission	1.4 m/s²
Rear wheels diameter	230 mm
Sound pressure level	92.2 dB
Front wheels diameter	200 mm
Maximum cutting height	100 mm
Minimum cutting height	25 mm
Grass collecting volume	80 L
Power source	Battery
Battery voltage	36 V

Weight and Dimensions

Depth	1650 mm
Width	690 mm
Height	1230 mm
Weight	44000 g
