Stihl TS700 User Manual

TS 700, TS 800
English
49
Abrasive wheels (TS 800)
Contact your STIHL dealer for
information regarding special
accessories that may be available for
your product.
Users of this unit should carry out only
the maintenance operations described
in this manual. STIHL recommends that
other repair work be performed only by
authorized STIHL servicing dealers.
Warranty claims following repairs can be
accepted only if the repair has been
performed by an authorized STIHL
servicing dealer using genuine STIHL
replacement parts.
Genuine STIHL parts can be identified
by the STIHL part number, the
{ logo and, in some cases, by
the STIHL parts symbol K. The
symbol may appear alone on small
parts.
Diamond abrasive wheels
Minimum outside diameter of
front thrust washer:
4.06 in.
(103 mm)
Max. depth of cut: 4.9 in.
(125 mm)
Outside diameter: 16 in.
(400 mm)
Bore diameter/spindle
diameter:
0.787 in.
(20 mm)
Tightening torque: 22 lbf ft
(30 Nm)
Composite resin abrasive wheels
Minimum outside diameter of
front thrust washer:
4.06 in.
(103 mm)
Max. depth of cut: 5.6 in.
(145 mm)
Diamond abrasive wheels
Minimum outside diameter of
front thrust washer:
4.06 in.
(103 mm)
Max. depth of cut: 5.6 in.
(145 mm)
Special Accessories Maintenance and Repairs

Stihl TS700 Specifications

General

Max. Engine Speed	9, 300 rpm
Displacement	98.5 cm³ (6 cu. in.)
Weight	25.6 lbs
Maximum Wheel Size	350 mm
Fuel Capacity	40 oz
Arbor Size	20 mm
Maximum Cutting Depth	125 mm (4.9 in)
