Quad Aer Trouble Shoong
Turn unit o before any troubleshoong
Tines won’t go up/down
1. Turn pressure knob to the right.
2. Check UP/TRANSPORT/DOWN switch posion.
3. Set nes to default down.
4. With the unit o, check the aux belt.
5. With the unit o, check the gear pump and engine
pulley.
Ensure key stock is present in the pulley
1. Check relay under the ignion key. The relay should
click when the foot pedal is depressed.
2. Ensure wiring harness has a good connecon with
the UP/TRANSPORT/DOWN switch and electronic
valve body.
3. Pressure check gear pump should be 800 PSI Re-
place if faulty.
4. Replace li cylinder.
Foot switch doesn’t work
1. Check UP/TRANSPORT/DOWN switch posion.
2. Check plug connecon at the footswitch. Remove
any debris if present.
3. Check relay under the ignion key. The relay should
click when the foot pedal is depressed.
4. Check both fuses by the engine.
5. Replace the footswitch or the UP/TRANSPORT/
DOWN switch.
Tines bending or breaking
1. Some nes breaking are common in the ordinary
course of operaon.
2. Eliminate ght turns with the nes in the ground.
