MOUNTING HIP
SUPPORTS
Mounting:
* Use the 5 mm Allen key to mount the holder
(A) on the side of the chair
* Mount the hip support in the holder (B). Please
be aware that it 'clicks' into place.
Dismounting:
* Click on (C) to dismount the hip supports.
Adjustment:
* Add extra distance pieces (D) to adjust the
width.
* Adjust the hip support in the slot (E) to adjust
the depth.
Any adjustments and addition of acces-
sories must be placed and fitted correctly
and checked before every use.
