15
A
B
C
"CLICK"
"CLICK"
G
B
GB
MAKE THE
STINGRAY READY
FOR TRANSPORT
Transport fittings:
* Use an 5 mm Allen key to mount the two
fittings (A) in the holes on both sides of the
Stingray
* Use an 5 mm Allen key to mount the two
fittings (B) in the holes on the back of the
Stingray. The transport fittings (B) are equip-
ped with a secure symbol (C).
Position the back:
The back MUST be placed in vertical po-
sition during transportation.
The chair is approved for transportation at
max load 40 kg.
