REVERSIBLE SEAT
The Stingray seat is reversible 180
°
. The easiest
way is as follows:
* Activate the brakes (A)
* Tilt the complete seat unit backwards (B)
* Unlock the handles (C)
* Tip the push handle upright (D)
* Lock the handles (C)
* Turn the seat unit until it clicks into place (E)
The seat unit will only turn one way. An
arrow on the push brace will indicate the
correct way to turn.
The seat can be reversed with or without the
child seated.
When turning the seat, please be careful
not to get fingers caught between the seat
and frame.
GB
SEAT MOUNTING /
DISMOUNTING
Make sure that the red security handle (A)
on the back is tipped UP before mounting.
Make sure that the red security handle (A)
on the back is tipped DOWN after mounting.
* Mount the seat onto the frame and make sure
it clicks into place.
* Push down the red handle (A)
To dismount:
* Tip up the red handle (A)
* Squeze the two handles (B) together, pull the
seat forwards and remove it from the frame.
