Stingray r82 - Storing the Stingray

13
E
C
B
D
A
F
G
B
STORING THE
STINGRAY
The Stingray compacts very easily and therefore
is easy to take anywhere.
There are two ways to store the Stingray:
1) with the seat on the frame
2) the seat is dismounted before storing
With the seat on the frame:
* Activate the brakes (A)
* Tip the back rest all the way forward (B)
* Unlock the handles (C)
* Turn the push handle upright (D)
* Push down (E) to collapse the back end
With the seat dismounted:
To dismount the seat, release the handle (C)
on the back of the chair. Then follow the above
steps.
When storing the Stingray, please be ca-
reful not to get fingers caught between the
cabon frame and the upper frame part.
To store the Stingray completely, remove
the canopy, tray, shopping basket and hand
brace, if any.
GB
