PARKING BRAKES
The Stingray is available with either a one-bar
or a two-point parking system.
Stingray with one-bar parking system:
* Activate the brakes at one side by pressing
down the pedal (A)
Kiddie boards from other suppliers can
easily be mounted on this system.
Stingray with two-point parking system:
* Activate the brakes at each side by pressing
down the pedals (B)
Always make sure to activate the brakes
whenever the Stingray is parked.
Check on a regular interval that the locks
click into place and the holes are not filled
with grease or dirt.
GB
i
HAND BRAKES
The Stingray is available with or without hand
brakes mounted.
* Squeeze the handle (A) to brake
* Squeeze the handle (A) and push in the red
button (B) to lock the brake
* Squeeze the handle (A) to unlock the brake
