Power Requirements
If your Fridge/Freezer is cutting out prematurely, it could be due to:
1. The low voltage protection being set too high on the Battery Monitor
2. DC power cable and/or connections are not suitable to carry the required
current. Check the power cable and all connections and adjust the Battery
Monitor switch at the rear of the unit.
NOTE: A battery charger may only be connected to the battery when the Fridge/
Freezer has been disconnected from the DC power source.
• Over-voltage may cause damage to the electronics of the Fridge/Freezer.
• Your Fridge/Freezer is equipped with reverse polarity protection. It protects
your Fridge/Freezer against reverse battery connection and short circuit.
• As a protection for your battery, the Fridge/Freezer switches OFF automatically
if the power source voltage is insufficient.
Operating your Fridge/Freezer
12V DC (Cont.)
IMPORTANT:
If a DC extension cable is required we recommended use of a 6mm dia.
(AWG11) 4.58mm2 Twin Sheath Two Core cable with direct connection to
the positive and negative battery terminals with 15A inline fuse protection.
• Always consult a qualied automotive electrician when using a DC extension
cable.
• The Fridge/Freezer is equipped with a multi-level Battery Monitor that
protects your vehicle battery against excessive discharging when the Fridge/
Freezer is connected to 12V or 24V DC power source.
IMPORTANT:
When using the Fridge/Freezer with 12V DC power supply, we recommended
setting the Battery Monitor switch to LOW.
