STMicroelectronics STM8 User Manual

stm8s_it.h (top part only)
#ifndef __STM8S_IT_H
#define __STM8S_IT_H
@far @interrupt void TIM4_UPD_IRQHandler(void);
/* Includes ------------------------------------------------------------------*/
#include "stm8s.h"
stm8s_it.c (top part only)
#include "stm8s.h"
#include "stm8s_it.h"
extern unsigned int value;
extern unsigned char n;
extern unsigned char seg;
extern const unsigned char num[10];
void TIM4_UPD_IRQHandler(void)
{
switch(seg)
{
case 1:
{
n = (value / 1000);
GPIO_Write(GPIOD, num[n]);
GPIO_Write(GPIOC, 0xE0);
break;
}
case 2:
{
n = ((value / 100) % 10);
GPIO_Write(GPIOD, num[n]);
GPIO_Write(GPIOC, 0xD0);
break;
}
case 3:
{
n = ((value / 10) % 10);
GPIO_Write(GPIOD, num[n]);
GPIO_Write(GPIOC, 0xB0);
break;
}
case 4:
{
n = (value % 10);
GPIO_Write(GPIOD, num[n]);
GPIO_Write(GPIOC, 0x70);
break;
}
}
seg++;
if(seg > 4)

STMicroelectronics STM8 Specifications

General

ADC Resolution	10-bit
Core	STM8
Maximum Clock Frequency	Up to 24 MHz
Flash Memory	Up to 128 KB
RAM	Up to 6 KB
EEPROM	Up to 2 KB
Operating Voltage	2.95 V to 5.5 V
Operating Temperature	-40°C to +85°C or +125°C
Communication Interfaces	UART, SPI, I2C
Package Options	LQFP, TSSOP, UFQFPN, SO
