Stobag Select - Fixing Bracket Distribution: 2 Folding Arms (Select-Plus, Extended); 325 cm 2 x S840; Fixing Bracket Distribution: 4 Folding Arms (Select-Plus); Select-Plus S8133

- 17 -
300cm 2 x S840
115 120 125 130 140 150 155 170 175 185 200 215 225 250 275 300 325 350 375 400 425 450
A1 a --- --- --- --- --- --- --- --- --- --- 10 10 10 10 10 10 10
K1 b --- --- --- --- --- --- --- --- --- --- 25 25 25 25 25 25 25
K2 c --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- ---
325cm 2 x S840
115 120 125 130 140 150 155 170 175 185 200 215 225 250 275 300 325 350 375 400 425 450
A1 a --- --- --- --- --- --- --- --- --- --- --- 10 10 10 10 10 10 10 10
K1 b --- --- --- --- --- --- --- --- --- --- --- 25 25 25 25 25 25 25 25
K2 c --- --- --- --- --- --- --- --- --- --- --- --- --- --- 138 150 163 175 188
350cm 2 x S840
115 120 125 130 140 150 155 170 175 185 200 215 225 250 275 300 325 350 375 400 425 450
A1 a --- --- --- --- --- --- --- --- --- --- --- --- 10 10 10 10 10 10 10
K1 b --- --- --- --- --- --- --- --- --- --- --- --- 25 25 25 25 25 25 25
K2 c --- --- --- --- --- --- --- --- --- --- --- --- --- --- 138 150 163 175 188
Select S8130
Select S8130
Select S8130
11
Select-Plus S8133
b
c
d
e
K1A1
a
A1K1K2 A2 K2A2K3W1K3
f
b
c
d
e
a
275cm 4 x S840
475 500 525 550 575 600 625 650 675 700 725 750 775 800 825 850 875 900 925 950 975 1000
A1 a 10 10 10 10 10 10 10
K1 b 25 25 25 25 25 25 25
K2 c --- --- 175 175 272 272 272
A2 d 190 190 190 190 287 287 287
K3 e 205 205 --- --- --- --- ---
W1 f --- --- 262 275 288 300 313
Select S8130
300cm 4 x S840
475 500 525 550 575 600 625 650 675 700 725 750 775 800 825 850 875 900 925 950 975 1000
A1 a --- 10 10 10 10 10 10 10 10
K1 b --- 25 25 25 25 25 25 25 25
K2 c --- 195 195 230 230 272 272 285 298
A2 d --- 210 210 245 245 287 287 300 313
K3 e --- --- --- --- --- --- --- --- ---
W1 f --- --- 262 275 288 300 313 325 338
Select S8130
Fixing bracket distribution with 4 folding arms /
TW /
Distribución de los soportes con 4 brazos articulados
Ant.
