Pin assignment ISDN plug (8 pin; RJ45; ITU I.430/ISO 8877)
Pin Signal (S
0
)
1 Not connected
2 Not connected
3 [2a] Rx+ (Receive +)
4 [1a] Tx+ (Transmit +)
5 [1b] Tx- (Transmit -)
6 [2b] Rx- (Receive -)
7 Not connected
8 Not connected
