TA+P2I
User Manual
Release r06 www.stollmann.de Page 16 of 18
7 Technical features
Function TA+P2I
Power supply External plug in power supply
Input 100-240V AC
Output 12V DC 1,25A
Dimensions 127 x 88 x 27 mm
CE conformity CE Europe
7.1 Analogue ports
Function TA+P2I
Plug 2 x RJ11
Ringing detection 20 to 50 Hz
Off-Hook / On-Hook signaling
√
DTMF dial
√
Barring incoming call
√
CLIP detection (FSK)
√
Busy tone detection
√
Pin assignment analogue plug (6 pin; RJ11)
Pin Signal (a/b)
1 Not connected
2 Not connected
3 a (TIP)
4 b (RING)
5 Not connected
6 Not connected
7.2 ISDN ports
Function TA+P2I
ISDN interface 1 x I.430 LT-S mode (S-Bus, BRI)
Plug 2 x RJ 45
Terminating resistors Integrated, 2 x 100 Ohm
Phantom feeding ISDN-Bus 4 Watt
Supplementary services TA+P2I MSN, DDI, call waiting, hold, resume, three party
conference, call forwarding
Supplementary services transparent using
DTMF
All available on analogue line
D channel protocol DSS1 LT-S mode
Interfacing modes Multipoint
B channel G.711 a-law (analogue voice)
Configuration Block dial via ISDN phone
