1.1 Specifications - Stone RP522 & RP652
Dimensions in in / mm
Length L
Length L1
Length L2
Height H
Height H1
Height H2
Width basic unit l
Width basic unit ll
Weights in lbs / kg
Basic unit l
Basic unit ll
Drive
Engine Type
Type of Construction
Performance HP / kW
At Revolutions (min
-1
)
Cooling
Fuel Consumption (g/h / l/h)
Max. Gradient
Max. Gradeability
Drive
Control Fwd/Rvs
Operating Speed in ft/min / m/min
Basic unit l
Basic unit ll
Vibration
Centrifugal Force (lbs / kN)
Vibration Frequency (vpm / Hz)
Amplitude (in / mm)
Maximum Performance in sq/ft/hr / m
2
/hr
Basic unit l
Basic Unit ll
Filling Quantities in gal / l
Fuel
Optional Extras
Vulkollan Plate
RP522
44.88 in / 1140 mm
23.62 in / 600 mm
10.0 in / 254 mm
24.01 in / 610 mm
40.16 in / 1020 mm
46.46 in / 1180 mm
15.75 in / 400 mm
15.75 in / 400 mm
220.5 lbs / 100 kg
220.5 lbs / 100 kg
Honda GX 120
1 cyl. 4-stroke-gasoline
4.0 HP / 2.9 kW
3600
Air
.237 g/h / 0,9 l/h
20º
35%
via centrifugal clutch
and v-belt
hydraulic
0 - 82 ft/min / 0 - 25 m/min
0 - 82 ft/min / 0 - 25 m/min
4947 lbs / 22 kN
5880 vpm / 98 Hz
.047 in / 1.2 mm
6456 sq/ft/hr / 600 m
2
/hr
6456 sq/ft/hr / 600 m
2
/hr
.66 gal / 2.5 l
X
RP652
44.88 in / 1140 mm
27.56 in / 700 mm
12.99 in / 330 mm
29.13 in / 740 mm
40.16 in / 1020 mm
46.46 in / 1180 mm
19.69 in / 500 mm
27.56 in / 700 mm
407.9 lbs / 185 kg
429.9 lbs / 195 kg
Honda GX270
1 cyl. 4-stroke-gasoline
9.0 HP / 6.6 kW
3600
Air
.55 g/h / 2,1 l/h
20º
35%
via centrifugal clutch
and v-belt
hydraulic
0 - 72 ft/min / 0 - 22 m/min
0 - 62 ft/min / 0 - 19 m/min
6519 lbs / 29 kN
5700 vpm / 95 Hz
.047 in / 1.2 mm
7101 sq/ft/hr / 660 m
2
/hr
8606 sq/ft/hr / 800 m
2
/hr
1.58 gal / 6.0 l
X
