1. TECHNICAL DATA
Bulldog
®
Model Type TR24 TR34
Operating Weight lbs (kg) 2,900 lbs (1318 kg) 3,100 lbs (1406 kg)
L x W x H in (cm) 66 x 34 x 46.4 in
(167.7 x 86 x 119 cm)
66 x 34 x 46.4 in
(167.7 x 86 x 118 cm)
Drum Diameter in (cm) 19.7 in (50 cm) 19.7 in (50 cm)
Drum Width in (cm) 24 in (61 cm) 34 in (86.4 cm)
Engine hp (kw) 20 hp Hatz (15 kw) 20 hp Hatz (15 kw)
Operating Speed RPM (Hz) Up to 2,800 RPM (46.6 Hz) Up to 2,800 RPM (46.6 Hz)
Driving & Steering Hydrostatic Hydrostatic
Hydraulic Reservoir gal (l) 13 gal (49 l) 13 gal (49 l)
Fuel Tank Capacity gal (l) 3 gal (11.5 l) 3 gal (11.5 l)
Vib Frequency vpm (Hz) 2,000 vpm (33.3 Hz) 2,000 vpm (33.3 Hz)
Centrifugal Force lbs (kN) 15,709 lbs (69.87 kN) 15,709 lbs (69.87 kN)
Total Applied Force lbs (kN) 18,609 lbs (82.7 kN) 18,809 lbs (83.7 kN)
Static Linear Pressure PSI (N/cm) 60.4 PSI (105 N/cm) 48 PSI (85 N/cm)
Dynamic Linear Pressure PSI (N/cm) 327 PSI (572 N/cm) 247 PSI (432 N/cm)
Total Applied Linear Pressure PSI (N/cm) 387.7 PSI (677 N/cm) 295 PSI (516 N/cm)
Static Padfoot Pressure PSI (N/cm) 136.8 PSI (94.34 N/cm) 73.06 PSI (516 N/cm)
Dynamic Padfoot Pressure PSI (N/cm) 740 PSI (510 N/cm) 370 PSI (127.85 N/cm)
Total Applied Padfoot Pressure PSI (N/cm) 876.8 PSI (604.7 N/cm) 443.30 PSI (647.5 N/cm)
Gradeability: With Vib On
With Vib Off
45%
55%
45%
55%
Travel Speed: Hi Without Vib
Ft/min (m/min) Low With Vib
136 ft/min (41.5 m/min)
68 ft/min (20.7 m/min)
136 ft/min (41.5 m/min)
68 ft/min (20.7 m/min)
Maximum Lift in (cm) 27 in (10.62 cm) 27 in
(68.6 cm)
Tip Angle 42° 43°
Productivity sq ft/hr (sq m/hr) 8,160 sq ft/hr (758 sq m/hr) 10,798.47 sq ft/hr
(1,003.5 sq m/hr)
Standard Features Include: internal and external drum scrapers, drum covers, lift eye, dry element air filter, hydraulic
oil sight gauge, electric start, zero-turning radius, zero edge clearance, Snap-Tek
TM
electronic connection system.
Optional Features: Snap-Tek
TM
radio-frequency remote control kit, test port gauge kit.
1.1 - Stone Bulldog
®
– Specifications
