STORK TRONIC ST121-KD1KAR.112 User Manual

Order number: 900323.001 V1.74 Page 11
© Störk-Tronic 2021 • www.stoerk-tronic.com • Subject to modifications.
Parameter list software .112
H-- Temperature sensors
Para-
meter
Description of function Setting range Default
value
H1
Mains frequency 0: 50Hz
1: 60Hz
0
H11
Act. value sensor F1 Measured value, not adjustable
H12
Calibration sensor F1 (actual value correction) -20...+20.0°C 0,0
H13
Weighting factor sensor F1 0.50...1.50 1,00
H14
Selection sensor F1
Depending on hardware, not all types are available.
Sensor will be deactivated in this case.
0: not existing
1: PTC (-50..+150°C)
2: Pt100 2-wire (-100…+600°C)
3: Pt100 3-wire (-100…+500°C)
4: NTC (-40…+40°C)
5: Pt1000 2-wire (-100…+330°C)
6: Pt1000 3-wire (-100…+300°C)
7: 0-20mA
8: 4-20mA
1
H15
Software filter sensor F1 1 .. 32 8
H16
Display at 0/4mA and sensor selection H14=7/8
-99..+999 0,0
H17
Display at 20 mA and sensor selection H14=7/8
-99..+999 100
H21
Act. value sensor F2 Measured value, not adjustable
H22
Calibration sensor F2 (act. value correction) -20...+20,0°C 0,0
H23
Weighting factor sensor F2 0,50...1,50 1,00
H24
Selection sensor F2
see H14
1
H25
Software filter sensor F2 1 .. 32 8
H26
Display at 0/4mA and sensor selection H24=7/8
-99..+999 0,0
H27
Display at 20 mA and sensor selection H24=7/8
-99..+999 100
H31
Act. value sensor F3 Measured value, not adjustable
H32
Calibration sensor F3 (act. value correction) -20...+20,0°C 0,0
H33
Weighting factor sensor F3 0,50...1,50 1,00
H34
Selection sensor F3
see H14
0
H35
Software filter sensor F3 1 .. 32 8
H36
Display at 0/4mA and sensor selection H34=7/8
-99..+999 0,0
H37
Display at 20 mA and sensor selection H34=7/8
-99..+999 100
H41
Act. value sensor F4 Measured value, not adjustable
H42
Calibration sensor F4 (act. value correction) -20...+20,0°C 0,0
H43
Weighting factor sensor F4 0,50...1,50 1,00
H44
Selection sensor F4
see H14
0
H45
Software filter sensor F4 1 .. 32 8
H46
Display at 0/4mA and sensor selection H44=7/8
-99..+999 0,0
H47
Display at 20 mA and sensor selection H44=7/8
-99..+999 100
H51
Display of weighted mean value of F1+F2
H51 = (H53*H11 + (100-H53)*H21)/100
H53
Weighting of sensor F1 for H51
0 ... 100% 100
H99
Password of parameter level H--
-99 ... 999 0
