Key
Position
Row /
Column
2210
UK Layout.
2210
US Layout.
PC/AT Code
(Code Set 2)
Base
Shifted
Base
Shifted
34
R3C6
H
H
h
H
33
35
R3C7
J
J
j
J
3B
36
R3C8
K
K
k
K
42
37
R3C9
L
L
l
L
4B
38
R3C10
;
:
;
:
4C
39
R3C11
‘
@
‘
“
52
40
R4C14
Shift
Shift
12
41
R4C1
\
|
\
|
61
42
R4C2
Z
Z
z
Z
1A
43
R4CE
X
X
x
X
22
44
R4C4
C
C
c
C
21
45
R4C5
V
V
v
V
2A
46
R4C6
B
B
b
B
32
47
R4C7
N
N
n
N
31
48
R4C8
M
M
m
M
3A
49
R4C9
,
<
,
<
41
50
R4C10
.
>
.
>
49
51
R7C10
↑
↑
E0,75
52
R4C11
/
?
/
?
4A
53
R5C0
[
{
[
{
54
54
R5C1
]
}
]
}
5B
55
R5C10
Control
Control
E0,27
56
R6C13
Alt
Alt
11
57
R5C5
Space
Space
29
58
R5C6
Space
Space
29
59
R7C13
Alt Gr
Alt Gr
E0,11
60
R7C9
←
←
E0,6B
61
R7C11
↓
↓
E0,72
62
R7C12
→
→
E0,74
Release Codes.
The PC/AT release code for each key is the Scan Code preceded by H’F0.
Example: Q – H’F0’, H’15.
Exception: Keys with Scan Codes starting with H’E0, the release code sequence
(for example LEFT ARROW) is as follows: H’E0’, H’F0’,H’6B.
