Product description
Instructions for use • OR1 SmartScreen • PQJ219_EN_V1.0_04-2021_IFU_CE-MDR 9
4 Product description
4.1 Product overview
Front
1
2
3
4
5
Rear
1 Potential equalization connection 4 12V direct current input socket
2 DisplayPort video output sockets 5 Transport lock
3 USB-B port
4.2 Possible combinations
It is recommended that the suitability of the products for the planned procedure be checked
prior to use. Please note that the products listed here may not yet be available in all countries
due to differences in approval requirements.
The product can be combined with the following components:
Product name Item number
Cable set WO10042
Power supply unit WM20001
DisplayPort cable WA1000C
USB-A to USB-B cable 20090179
