Thank you for choosing a
British built appliance by Stoves
We hope the following information
will help you to quickly familiarise
yourself with the features of the
appliance, and to use it successfully
and safely.
Our policy is one of constant
development and improvement. Strict
accuracy of illustrations and specifications
is not guaranteed. Modification to
design and materials may be necessary
subsequent to publication.
This appliance must be installed in
accordance with the regulations in
force, and only in a well ventilated
space. Read the instructions before
installing or using this appliance.
This appliance is designed to be
installed free-standing or flush to
base units.
Your 1st Year Guarantee
To fulfil the conditions of your guarantee,
this appliance must be correctly
installed and operated, in accordance
with these instructions, and only be
used for normal domestic purposes.
Please note that the guarantee, and
Service availability, only apply to the
UK and Republic of Ireland.
Before using the appliance for
the first time, remove any protective
polythene film and wash the oven
shelves and furniture in hot soapy
water, to remove their protective
coating of oil. Even so, when you first
turn on the oven or grill you may
notice a smell and some smoke.
The User’s Section in this handbook covers
the operation of the appliance, but to
help you make the most of your cooker,
we have produced the accompanying
Cooking Guide which gives more
details of its features and benefits.
Glass door panels
To meet the relevant Standards of
Domestic cooking appliances, all the
glass panels on this appliance are
toughened to meet the fragmentation
requirements of BS3193. This ensures
that, in the unlikely event that a panel
breaks, it does so into small fragments
to minimise the risk of injury.
Please take care when handling, using
or cleaning all glass panels as any
damage to the surfaces or edges may
result in the glass breaking without
warning or apparent cause at a later
date. Should any glass panel be
damaged, Stoves strongly recommend
that it is replaced immediately.
2
INTRODUCTION
Data badge
Located on the lower part of the front
frame.
Type of gas
This cooker must only be used with
either Natural gas or LP gas, as specified
on the appliance data badge.
Gas category
Natural gas - I
2H, LP gas - I3+, I3BP
Pressure setting
G20 Natural gas @ 20 mbar
G30 Butane @ 28 mbar
G31 Propane @ 37 mbar
Aeration
Fixed
Appliance class
Class 1, freestanding
Electrical supply
230 - 240V ~ 50Hz
Warning: This cooker must be earthed.
Spark generators
Mains powered 7 outlet, controlled
by a single switch at the left of the
fascia to individual electrodes.
Hob
Burners have burner heads and caps
which are removable for cleaning.
Concealed electrodes to each burner.
Electrical ratings
Main oven fan element 2400W
Top element 960W
Base element 960W
Grill 1725 / 2685W
Stir fan 30W
Secondary oven 1670W
Grill 1465 / 2300W
Lights (4 x 25W) 100W
Cooling fans (2 x 23W) 46W
Maximum load 5160W
Countries of destination
(GB) Great Britain, (IE) Ireland
31
Hotplate burner Nominal Injector
Grammes per hour
Rate Qn marking Butane Propane
Natural Auxiliary burner (x 2) 1.0kW 72 X - -
gas Semi rapid burner (x 2) 2.0kW 100 Z - -
Rapid burner (x 2) 2.9kW 1.1 Y - -
Wok burner 3.5kW 1.24 Y - -
Total heat input ∑Qn 15.3kW - - -
LP Gas Auxiliary burner (x 2) 1.0 kW 50 73
g/h
72
g/h
Semi rapid burner (x 2) 2.0 kW 70 145
g/h
143
g/h
Rapid burner (x 2) 2.9 kW 85 211
g/h
207
g/h
Wok burner 3.5 kW 90 254
g/h
250
g/h
Total heat input ∑Qn 15.3kW -
1112 g/h
1094 g/h
TECHNICAL DATA
