STOVES 900GTF - Troubleshooting Guide; Main Oven Function Faults (Chart 3)

CHART 3 (MAIN OVEN)
FAULT FINDING
CHECK FOR 230V AT ‘C’ ON PRESSURE
SWITCH AND LOGIC CONTROL PCB
RECTIFY WIRING
CHECK FOR 230V FROM
OVEN SWITCH THROUGH
PROGRAMMER RELAY TO L1
ON LOGIC CONTROL PCB.
REPLACE LOGIC
CONTROL PCB.
HAS OVEN FAN STARTED
RECTIFY WIRING OR
PROGRAMMER
COOLING FAN OPERATES
CHECK FOR 230V AT OVEN
SWITCH AND THROUGH
PROGRAMMER RELAY
REPLACE FAN
CHECK FOR 230V ACROSS FAN CONNECTIONS
IGNITION GENERATOR
STARTS SPARKING
TURN OVEN CONTROL KNOB
TO DESIRED SETTING
