STOVES 900GTF - Troubleshooting Guide; Burner Lighting and Ignition Faults

FAULT FINDING
NEON INDICATOR
LIGHTS?
GO TO CHART 4
IS GAS LIGHTING AT
BURNER?
CHECK IGNITION ELECTRODE IS
CORRECTLY POSITIONED. CHECK HT
LEAD IS NOT DAMAGED
SPARKING CEASES
AFTER PERIOD?
GO TO CHART 4
RECTIFY WIRING OR
REPLACE NEON
INDICATOR
GAS LIT AT BURNER?
NO
NO NO NO
YES
YES
