STRATOS HSSD - Thorn AM521

World Patents Pending ©AirSense Technology Ltd. 1999
ISSUE 2.4
Page 37
TECHNICAL. MANUAL
Thorn AM521
Master
+ 3 Slaves
Master
+ 2 Slaves
Master
+ 1 Slave
Single
Master
Line in -ve Line 1
Line in +ve
Line connections
Line 2
Line out -ve Line 3
Line out +ve Line 4
