STRATOS HSSD - Remote Monitor Format

World Patents Pending ©AirSense Technology Ltd. 1999
ISSUE 2.4
Page 44
TECHNICAL. MANUAL
Information Size
Product id of detector (see above) byte
Version number of software byte
Total number of detectors in data structures (n) byte
Number of enabled detectors byte
Reference enable flag byte
Currently displayed detector byte
the following data structures have n elements with n being the total number of
detectors as shown above the first element is detector 1, 2 etc
Bargraph level (0-10) bit 8 is set if in FastLearn n bytes
Aux LED flag (0 = off, 1 = on) n bytes
PreAlarm LED flag (0 = off, 1 = on) n bytes
Fire LED flag (0 = off, 1 = on) n bytes
Flow Fault LED flag (0 = off, 1 = high, 2 = low, 254 = flash) n bytes
Head fault LED flag (0 = off, 1 = on, 254 = flash) n bytes
Isolated LED flag (0 = off, 1 = on, 254 = flash) n bytes
Separator LED flag (0 = off, 1 = on, 254 = flash) n bytes
Battery fault flag (0 = off, 1 = on) byte
Mains fault flag (0 = off, 1 = on) byte
Dimmed display flag (0 = off, 1 = on) byte
the following four data structures are transmitted n times with n being the total
number of detectors as shown above the first element is detector 1, 2 etc
Fire level (0-255) byte
PreAlarm level (0-255) byte
Aux level (0-255) byte
Detector level (0-255) byte
Selected detector byte
Selected function byte
Function value byte
XOR sum of all data byte
Extended remote monitor mode is not supported by the remote software but is
provided for other products that remotely access the Stratos range of detectors like
SenseNET™.
Remote monitor
format
