Stratus 3i - Wiring Diagrams

Stratus 3i Installation Guide
600840-000052
Page 6 of 8
Stratus ES to Stratus 3i Wiring Diagram
PIN DESCRIPTION PIN
19 AUX +5V POWER 1
36 AUX +5V POWER 2
17 AUX +5V POWER 3
- - 4
- 5
23 RS232-TX AUX 6
6 RS232-TX GPS 1PPS 7
- AIRCRAFT GROUND 8
- - 9
37-DSUB 9-DSUB
STRATUS ES
AI RCRAFT P OWE R 1
AI RCRAFT P OWE R 2
AIRCRAFT GROUND 1
AIRCRAFT GROUND 2
28V LIGHTING BUS HI
14V LIGHTING BUS HI
EXTERNAL STANDBY
EXTERNAL SUPPRESS IN
EXTERNAL SUPPRESS I/0
RS232 EXTERNAL GPS
EXTERNAL GPS COMMON (GND)
EXTERNAL IDENT
EXTERNAL SQUAT SWITCH
ALTITUDE A1
ALTITUDE A4
ALTITUDE B2
ALTITUDE C1
ALTITUDE C4
ALTITUDE D4
ALTITUDE A2
ALTITUDE B1
ALTITUDE B4
ALTITUDE C2
AUX +5V POWER
AUX +5V POWER
AUX +5V POWER
RS232-TX AUX
RS232-TX GPS 1PPS
ALTITUDE COMMON (GND)
XP NDR A NTE NNA
GPS ANTENNA IN
(STRATUS ESG ONLY)
ADS-B AUX
2
21
1
20
15
33
7
14
32
3
18
25
26
9
10
11
12
13
27
28
29
30
31
19
36
17
23
6
37
11-33 VDC AIRCRAFT POWER
D-SUB
5A
TO LIGHT DIMMING BUS
PARALLEL ALTITUDE ENCODER
MUTUAL SUPPRESSION (ARINC 709)
DME
TRANSPONDER 2
OPTIONAL
RF
(BNC)
XPNDR
ANTENNA
RF
(TNC)
ALTITUDE COMMON (GND)
IDENT INPUT
OPTIONAL
WoW
GPS SOURCE
RS232 OUT
COMMON GROUND
1
2
3
6
7
8
9-
DSUB
RF
(BNC)
ADS-B AUX
