Stratus 3i - LED Indicator Status

Stratus 3i Installation Guide
600840-000052
Page 8 of 8
LED Indicator Status
Label
LED Color
LED Status
Meaning
GPS
Green
Solid
3-D GPS lock achieved
Yellow
Flashing
No GPS lock, searching for signal.
Off
Off
Receiver is powered off.
Power
Green
Flashing
Receiver is powered on and operational.
Off
Off
No power is being received; receiver is powered off.
ADS-B
Green Solid
ADS-B FIS-B signal has been received from
multiple towers in the past three seconds.
Yellow Solid
ADS-B FIS-B signal has been received from one
tower in the past three seconds.
Off Off
ADS-B FIS-B signal has not been received in the
past three seconds.
All
indicators
Briefly red
then green
Solid Receiver is powering on and calibrating.
Red
Flashing
Built-in-test failure. Contact support for assistance.
Yellow
Flashing
Installing firmware update.
Solid
Applying firmware update.
Green
Solid for two
seconds
Firmware update complete.
Off for five
seconds,
then flashing
Power button is pressed. After 30 seconds, factory
reset process begins.
Green to
yellow to
green
Solid Factory reset is complete.
© 2018 Appareo Systems, LLC. All Rights Reserved.
