SPARE PARTS
When ordering spare parts please quote part numbers as listed below:
NATURAL GAS L.P.G. (Propane)
Gas tap / FSD / piezo igniter BV50023 BV50147
Oxypilot assembly BA50004 BA50041
Injector BI70800 BI70530
Back ceramic BC11300 BC11300
Centre ceramic BC11296 BC11296
Front ceramic - set of 2 BC11295 BC11295
Set of 10 loose coals BC50032 BC50032
Fig. 12 Theme Plus outline drawing without trim
Lowline Version
