Stream HYDROBOX 900 - Table of Contents; Safety Cautions

Content
1
2
2.1
2.2
2.3
2.4
2.4
2.5
3
3.1
3.2
3.3
4
4.1
4.2
4.3
4.4
4.5
5
6
1
2
2
3
3
3
3
4
4
4
4
6
6
6
7
8
8
9
10
SAFETY CAUTIONS
PRODUCT DESCRIPTION
Product Overview
Model Description
Performance Parameters
Performance Curve
Overall Dimension
Working Condition
INSTALLATION
Product Structure
Installation Steps
Connect Power Cable
COMMISSIONING
Control Panel
Indicator Light
Quick Debugging
Automatic and Manual Mode
Parameter Settings
FAILURE AND TROUBLESHOOTING
WARRANTY
1 SAFETY CAUTIONS
1.1 Check before installation
In this manual or on the machine, the following symbols are used：
Please read this manual carefully before installation.
Installation and operation must comply with current safety regulations in the country
where the product is installed.
If the product is damaged or parts are missing, do not install or operate it. Failure to do
so may result in equipment damage or personal injury.
1.2.1 Please support the bottom of the product when installing and moving. Do not just
hold the case to prevent the product from being damaged. Never use the power
cable to carry or move the product.
1.2.2 The product should be installed away from flammable and explosive materials,
away from heat sources, and installed on flame retardant materials such as metal.
1.2.3 When using in an enclosed environment, install fans or other cooling equipment
and set vents to ensure that the environment temperature of the product is lower
than 45℃. Otherwise, the service life of the product may be reduced or the product
may be damaged due to the high environment temperature.
1.2.4 There must be a shield to prevent sunlight and rain when the controller is installed
outdoors.
DANGER: Denotes risk of personal injury or deaths.
CAUTION: Denotes medium risk of personal injury or damage to the tool.
1.2 Installation
1.3.1 Please confirm that the rated voltage and frequency of the product are consistent
with the voltage and frequency of the input power supply before wiring,otherwise
the controller may be damaged and result in serious injury.
1.3.2 Theground wire of product must not be connected incorrectly and must be reliably
grounded; otherwise, the pump case may be charged with electricity and lead to
serious injury.
1.3.3 The carrying capacity of the supply cable must be greater than the rated current of
the product.
1.3 Wiring
1
