Streamax X5-E0804 - System Diagram

User Manual for X5-E0804/E0408 V2.0
For more information, please visit our website www.en.streamax.com
7 - 44
RS232
RS232 X 2
RS485
RS485 X 2
Sensor
8 inputs, 2 outputs
Serial
G-sensor (Internal)
Speed
1 channel pulse speed detection
Interface
Interface (CP4) Optional
Power
Input
DC8-36V
Output
1A@12V,1A@5V
Physical
Characteristics
Dimension(L x W x H)
292.5x215x91.6mm (including shelf and back cover)
Weight
2.6 kg
Others
Water Proof Rate
IP54
1.5. SYSTEM DIAGRAM
To connect A
