Page 6
23/03/01
Diagram showing clearances required in boiler room.
The clearance details shown above are required for access to the boilers for maintenance purposes. Slight
variations may apply, depending on the specific installation.
ASSEMBLY INSTRUCTIONS FOR: Ca 7s / BCa 7s
