strex SP45 - AC Voltage; Resistance; Diode Test; Transistor hFE Test

AC VOLTAGE
DIODE
TRANSIROT hFE TEST ( 0-100)
RESISTANCE
Range Resolution Accuracy
200V 100mV ±1 .2% of rdg ± 10 digits
600V 1V
±1 .2% of rdg ± 10 digits
Range Description
-->+ Show the approx. forward voltage drop of the diode.
Range Test Range Test Current Test Voltage
NPN & PNP
0-1000
Ib-10µA
Vce=3V
Range Resolution Accuracy
200Ω 0.1Ω
±0.8% of rdQ ± 3 digits
2KΩ 1Ω ±0.8% of rdg ± 3 digits
20KΩ 10Ω ±0.8% of rdg ± 3 digits
200KΩ 100Ω
±0.8% of rdg ± 3 digits
2MΩ 1KΩ
±0.8% of rdg ± 3 digits
Overload protection : 600V de or rms. ac for all ranges. Frequency range : 40Hz to 400Hz ,
Response: Average responding, calibrated in rms. of a sine wave.
Overload Protection: 250V de or rms. ac.
Maximum open Circuit Voltage: 3.2V
Overload Protection: 250,V de or rms. ac for all ranges.
