3.7.2 Adjusting the presser (Fig. 18)
Remove the clamping screw on lever (1) Fig. 17.
For blind stitches, the adjustment must be made according to Fig. 18a for thick
materials and Fig. 18b for thin materials.
The presser is situated in the centre of the stitch plate opening and is usually offset by
1 mm to the left of the needle shaft’s centre. Just before the needle stitch is inserted,
it must be at a standstill when the tip of the needle is approx. 2.5 mm away.
Fig. 18
VEB100-2
VEB100-4
VEB100-5
a b
a b
a b
Fig. 19
