4.3.5 Sewing foot lifting
- Select parameter t 03 12 with keys "B and D" and confirm with "OK".
- Enter the value 0.190ms and confirm with "OK".
Parameter t 03 12 = Time after cutting the thread until the lifting of the fabric support
arm closes again after the pedal has returned from -1 to 0 position.
Fig. 28
Light is on, the fabric support arm remains open after the end of sewing and after releasing the pedal
position -2.
Light is off, the fabric support arm closes after the end of sewing and as soon as the pedal position -2 is
released.
E
K
P
Min
Max
Default
Unit
Description
Sewing foot lifting (FL)
t
03
11
0
255
255
Ms
Switch-on delay of the sewing
foot lift during machine
standstill
t
03
12
0,0
9,999
0,190
s
Switch-on delay of the sewing
foot lift at the end of the
seam
