Strong SRT32HF2003 - 8.0 SPECIFICATIONS

17
Problem Possible cause and solution
The remote control
does not work
1. hange the batteries. If you're using rechargable ones take care to use such with low self-
discharge
2. The batteries are not installed correctly or the types have been mixed
3. IR Sensor is blocked or maybe interfered from bright light
The TV switches o
after a certain time
Switch ON the TV and check settings for automatic STBY function, by default the TV switches OFF after 4
hours to full European low power regulations and help you to save energy.
NOTE: If the problem persists after these solutions, please contact your local support centre or send a support mail via our
website www.strong.tv.
8.0 SPECIFICATIONS
Audio
Audio Output: 32”: 5W
40”: 8W
Video
DVB-T: Reception range: VHF (174MHz ~ 230MHz), UHF (474MHz ~ 862MHz)
Input impedance: 75Ω
Channel Bandwidth: 7MHz/8MHz
Modulation: DVB-T: COFDM 2K/8K QPSK,16QAM,64QAM
DVB-S/S2: QPSK ,8PSK
DVB-T2: QPSK,16QAM,64QAM,256QAM
DVB-C: 16QAM, 32QAM, 64QAM, 128QAM, 256QAM
Video System: MPEG-2 MP@ML, MPEG-2 MP@HL, H.2 Main/Main- 10 prole, @L4.1, Support 8-bit/10-bit color
depth, 1920x1080@60fps
Sound System: MPEG-1 layer 1/2
System: DTV: DVB-T2, DVB-S2, DVB-C, DVB-T, DVB-S
ATV: PAL/SECAM/ NTSC
AV: PAL, NTSC
Connectors 32”
1x ANT IN 1x SAT IN
2x HDMI
1x USB
1x S/PDIF (optical)
1x AV IN
1x COMMONINTERFACE (CI)
Connectors 40”
1x ANT IN 1x SAT IN
3x HDMI
2x USB
1x S/PDIF (optical)
1x AV IN
1x COMMONINTERFACE (CI)
1x Headphones
General Data
Operating voltage: 100 ~ 240 V AC 50/60 Hz
Power consumption: 32": max. 55W
40": max. 74W
Operating temperature: 5 °C ~ +35 °C
Storage temperature: -15 °C ~ +45 °C
Operating humidity: 0% ~ 89% RH, non-condensing
Storage humidity: 0% ~ 85% RH, non-condensing
Dimensions (WxHxD) in mm: 32”: 732.5 x 80.6 x 434.7 mm
40”: 904.3 x 80.3 x 516 mm
Net-weight: 32”: 3.7 kg
40”: 5.4 kg
