Strong Super Trouper - Page 39

XST/037
PARTS LIST
Figure5
Item PartNo. Description
1 10048A00 Knob
2 48402000 Shaft,IrisHandle
3 4151530 ShoulderScrew
4 25017000 Bushing
5 24369000 BellCrank
- 7200075  LinkageBar(toItem8Iris;seeFigure5A)
6 4080621 Screw,8-32x5/8"PanHead
7 25034000 IrisClamp
8 24374000 Iris,4"Diameter
- 24372000  Adapter“C”Ring(notshown;seeFigure5A)
9 51226000 Stud,ChopperBlade
10 83773000 ApertureSupportPlate
11 51160000 PulleyStud(seeFigure4,Item28)
12 83163000 Pulley,Rear(seeFigure4,Item27)
13 4087100 Washer,#8
14 47191000 ChopperBlade
15 47191000 ChopperBlade
16 47982000 ChopperBladeSlideAssembly(2req’d.)
17 4080181 Screw,8-32x3/16"PanHead
- 4087004  Lockwasher,#8
18 4257102 Washer,1/4"S.A.E.
19 4507106 FrictionWasher
20 83134000 PullRod,LowerFade-OutBlade
21 4257000 Lockwasher,1/4"Split
22 4258001 HexNut,1/4-20
23 4107100 Washer,#10,.036"ThickBrass
24 4107101 Lockwasher,#10
25 4100250 Screw,10-32x1/4"PanHead
26 4107100 Washer,#10,.036"ThickBrass
27 4107001 Lockwasher,#10
28 4100250 Screw,10-32x1/4"PanHead
29 83351000 RetainerPlate,Fade-OutPivots
30 51226000 PivotStud,Fade-OutControl
31 83890000 FadeoutBracket,WeldedAssembly
32 83892000 LowerFade-OutBladeAssembly
33 83891000 UpperFade-OutBladeAssembly
