Strong Super Trouper - Operation

OPERATION
 REMOVETHEPLASTICCOVERfromthexenonbulb.Do notignitethelampwith
theprotectiveshippingcoveronthebulb.
 AGLASSHEATFILTERissuppliedtoreducethetemperatureattheopticalsystem
andcolorgels.Thislterisanarrowglassstripthatcoversonlythecenterportionofthebeam.Insert
theheatlterinthebracketprovidedontheinsideofthelamphouseatthefrontopening(seeFigure
2,Item2).Placethelterinpositionwith the coated surface facing the bulb.Thecoatedsurfaceis
indicatedbyasmallXXorothermarking.Topreventdamagetoopticalsystemcomponents,do not
operatethespotlightwiththelterremovedorreversed.
 SECURETHELAMPHOUSECOVERwiththe(4)tamperproofscrewsusingthe
specialscrewdriverprovided.Thecovermustbesecurelyinpositiontoactuatetheinterlockswitch
andpermitlampignition.
 CLOSETHECIRCUITBREAKERonthexenonpowersupplytoenergizethepower
supply.Theblowersinthepowersupplyandinthelamphousewillstart;thelamphouseblowerwill
actuatetheairintakeinterlockswitchtopermitbulbignition.Thelampandpowersupplyblowers
willoperatecontinuouslyuntilthexenonpowersupplyisde-energized.
 PLACETHELAMPSWITCHintheONpositionandthexenonbulbwillignite.
Allowafewminutesforthecurrenttostabilize,andreadthelamphouseammeter.Thebulbmust
beoperatedwithinthecurrentrangespeciedbythebulbmanufacturer.Therangesforthexenon
bulbsapprovedforusewiththeXenonSuperTrouperareasfollow:
 WATTAGE NOMINALCURRENTDONOTEXCEED
 1000  50A. 58A.
 1600  65A. 70A.
 2000  75A. 90A.
 ADJUSTTHEPOWERSUPPLYasinstructedinthepowersupplymanualforthe
correctoperatingcurrent.Thecurrentsettingmustbeincreasedintimetocompensateforbulbaging,
butdo not,atanytime,exceedthemaximumcurrentrating.
 REMOVETHEREARCOVERPANEL(twoblackplasticpull-typeknobs)toexpose
thebulbpositionadjustmentcontrol.
 THECENTERSECTIONofthecontrolisathreadedmemberthatfocusesthebulbin
relationtothereector.Turningthisadjustmentmovesthebulbonthehorizontalplane,intoorout
ofthereector.Rotatingthissectionclockwisemovesthebulbawayfromthereector.Thesmall
knurledscrewtotheleftofthissectioncanbetightenedtolockthefocusingmechanisminplace
afterthebulbalignmentprocedurehasbeencompleted.
XST/012
