Strong Super Trouper - Major Subassemblies

XST/038
Item PartNo. Description
34 51153000 SpacerBushing,Fade-OutControl
35 83133000 PullRod,UpperFade-OutBlade
36 00919000 CotterPin,1/16"x1/2"
37 83143000 Fade-OutControlBracket
38 51155000 ShaftHandle,Fade-OutControl
- 10048A00  Knob
39 4318004 HexNut,5/16-18,Flexlock
40 4257102 Washer,1/4"S.A.E.
41 4507106 FrictionWasher
42 51498000 ChopperPullRod(Short)
43 51452000 ControlShaft,Choppers
44 10048A00 Knob
45 4080250 Screw,8-32x1/4"PanHead
46 4087004 Lockwasher,#8
47 47170000 IrisStop(asshown)
48 51488000 ChopperControlBracket
49 51153000 SpacerBushing,ChopperControl
50 4257000 Lockwasher,1/4"Split
51 4258001 HexNut,1/4-20
52 4318004 HexNut,5/16-18Flexlock
53 51497000 ChopperPullRod(Long)


MAJORSUBASSEMBLIES

 83788000 Iris&ChoppersAssembly
 83790000 Fade-OutAssembly
7201305GOBOHOLDERKIT(optional;seePage17)
 7201304 GoboHolder
 7210299 SlideChannel,Left
 7201300 SlideChannel,Right
 4101250  SlideChannelMountingScrew,10-32x1-1/4"
 7201303 StopScrewMountingBracket
 4100500  MountingScrew,StopScrewBracket
 4101250 StopScrew,10-32x1-1/4"SocketHead
PARTS LIST,Figure5(continued)
