Strong Super Trouper - Page 41

XST/039
PartNo. Description
2170029 SpringWasher
24369000 BellCrank
24372000 AdapterRing
24374000 Iris,4"Diameter
25017000 Bushing(with4151530)
25034000 IrisClamp
4040310 Screw,4-40x5/16"
406037B Screw,6-32x3/8"
4080621 Screw,8-32x5/8"
4151530 ShoulderBolt
48402000 IrisControlHandle
83773000 ApertureSupport
7200075 Link
81432000 ShoulderScrew
FIGURE 5A
48402000
24369000
406037B
2170029
4151530,
25017000
406037B
24374000
7200075
4080621
25034000
24372000
83773000
(ref. Fig.5,
Item 10)
4040310
81432000
