Stryker CrossFlow Service Manual

EN-34
DRAFT
h
1 m / 39 in
• Gather the following equipment:
• disposable Inow Cassette tube set
• container lled with water
• uid bag (3L)
• Follow the instructions in this manual to power on the pump,
insert the Inow Cassette, select a preference le, and select a
joint�
• Suspend a uid bag 1m/39in on its holder and connect the
bag to the tubing according to the diagram�
• Discard the protective cap on the tubing (if needed), and
immerse the end of the tubing into a container lled with
water�
• Set the Pressure to 50mmHg and Flow to 20%, according to the
instructions in the “Set the Pressure and Flow” section of this
manual�
• Remove air from the inow tubing according to the instructions
in the “Prime the Inow Tubing” section of this manual�
• Press to start the pump� Allow the tubing to
completely ll with uid�
• Press to stop the pump� The actual pressure display
will show approximately 0–5 mmHg�
• Remove the tubing from the container and hold it at a given
water column height (h) indicated in the table below� Ensure
the tubing in the water column is completely lled with uid�
• Read the actual pressure displayed on the pump� The test has
been successfully completed if the actual pressure on the pump
is within the range indicated in the table below for a given
height of the water column�
Height of water column (h)
Acceptable actual
pressure (mmHg)
Inches Centimeters
12 30 20–25
18 45 30–35
24 60 40–45
46 90 65–70
5� Inow Flow Rate
• Gather the following equipment:
• disposable Inow Cassette tube set
• uid bag (3L)
• stopwatch
• one 1L measuring cup
• Follow the instructions in this manual to power on the pump, insert the Inow Cassette, select a
preference le, and select a joint�
• Suspend a uid bag 1m/39in on its holder and connect the bag to the tubing according to the
diagram�
• Discard the protective cap on the tubing (if needed), and place the end of the tubing into a container
lled with water�
• Set the pressure to 150mmHg and ow to 50%�
• Remove air from the inow tubing according to the instructions in the “Prime the Inow Tubing”
section of this manual�
• Clamp o the tubing in the measuring cup without stopping the pump�
