Definitions
The symbols located on the equipment and/or labeling
are defined in this section or in the Symbol Definition
Chart. See the Symbol Definition Chart supplied with
the equipment.
Colors
The collet nose is marked with a color stripe to
facilitate wire/pin size selection. See Description table
for diameter ranges.
COLOR DEFINITION
Green
This collet is intended for use with
small diameter wires/pins (0.7 to
2.0 mm).
Orange
This collet is intended for use with
medium diameter pins (2.0 to
3.2 mm).
Blue
This collet is intended for use with
large diameter pins (3.0 to 4.2 mm).
Symbols
SYMBOL DEFINITION
General warning sign
Alignment mark
S 0.7 1.4mm
Allowable size range of small
(S) diameter wires/pins
M 1.1 1.6mm
Allowable size range of
medium (M) diameter wires/
pins
L 1.6 2.0mm
Allowable size range of large
(L) diameter wires/pins
2.0
mm
0.7
Single
Single Trigger — This
attachment is intended for
use with single trigger rotary
handpieces only.
2.0
mm
0.7
Dual
Dual Trigger — This
attachment is intended for use
with either single trigger or
dual trigger rotary handpieces.
2.0
mm
0.7
Dual
Full wire/pin diameter range
of collet
