Stuart Turner Showermate Series - Typical Installation

- 2 -
TYPICAL INSTALLATION (SHOWERMATE PUMP)
The plumbing installation must
comply with the following:
The Water Supply (Water Fittings) Regulations 1999.
BS6700 and building regulations.
Be installed by a competent person.
 If in doubt consult Stuart Turner Ltd.
Showermate Single pumps are not suitable for boosting a single side of a dual flow
mixer valve or tap. Consult Stuart Turner for alternative pump.
Item 1 = Service valves (not supplied).
Item 2 = Inline suction strainers (not supplied).
Item 2 = Inline suction strainers (not supplied).
Positive head 100 mm minimum from base of tank
Positive Duty Twin Pump System
Fig. 1
Positive head 100 mm minimum from base of tank
1
2
1
1
1
1
1
1
2
1
1
1
1
2
2
1
1
2
Fig. 3
Positive Duty Single Pump System
Fig. 2
Fig. 4
2
