E-6
INSTALL WOODEN LEGS
Before installation, ensure all accessories to install the stand are ready.
1. Turn the unit upside down.
2. Screw tighten the 4 WOODEN LEGS (provided) into the respective METAL
BRACKET (FOR WOODEN LEGS).
3. Once completed assembly, turn back to the upright position.
LOCATION OF CONTROLS
1. CD ACTIVATE COVER WITH TURNTABLE SHAFT
2. 12 INCH TURNTABLE FELT MAT
3. TURNTABLE PLATTER
4. 45 RPM ADAPTOR
5. CUE LEVER
6. TONE ARM REST/CLIP
7. TONE ARM
8. CARTRIDGE
9. PITCH CONTROL KNOB
29 30
31
27 28
25
32
34
33
35
08
09
01
02
03
04
05
07
06
14
36
26
12
11
10
16
19
22 23
24
21
18
15
13
17
20
