Studer OnAir 2500 Manual

Part No. Qty. Type/Val. DescriptionPos.Idx. Part No. Qty. Type/Val. DescriptionPos.Idx.
OnAir 2500
Page: 7 of 7
Main Board 1.943.630.22 ( 0)
R 557 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 558 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 559 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 560 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 561 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 562 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 563 57.69.1000 0R0 060301 pce
R 564 57.61.1332 3k3 MF, 1%, Chip 0603, E1201 pce
R 565 57.61.1332 3k3 MF, 1%, Chip 0603, E1201 pce
R 566 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 567 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 568 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 569 57.61.1152 1k5 MF, 1%, Chip 0603, E1201 pce
R 570 57.61.1152 1k5 MF, 1%, Chip 0603, E1201 pce
R 571 57.69.1000 0R0 060301 pce
R 572 57.61.1223 22k MF, 1%, Chip 0603, E1201 pce
R 573 57.61.1222 2k2 MF, 1%, Chip 0603, E1201 pce
R 574 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 575 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 576 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 577 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 578 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 579 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 580 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 581 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 582 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 583 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 584 57.61.1105 1M0 MF, 1%, Chip 0603, E1201 pce
R 585 57.61.1123 12k MF, 1%, Chip 0603, E1201 pce
R 586 57.61.1561 560R MF, 1%, Chip 0603, E1201 pce
R 587 57.61.1479 4R7 MF, 2%, Chip 0603, E1201 pce
R 588 57.61.1479 4R7 MF, 2%, Chip 0603, E1201 pce
R 589 57.61.1221 220R MF, 1%, Chip 0603, E1201 pce
R 590 57.61.1221 220R MF, 1%, Chip 0603, E1201 pce
S 1 55.60.0104 4p SMD DIL-Switch01 pce
T 1 63.60.0021 1:1 Ethernet Transformer 10/10001 pce
T 2 63.60.0011 1:1 AES/EBU Transformer01 pce
TP 16 54.33.6010 2.8*0.8 PCB-Flachstecker, gerade01 pce
XBA 1 89.01.2703 Batterie-Halter für CR 203201 pce
XIC 92 53.60.0244 44p PLCC, SMD01 pce
XIC 94 53.60.0244 44p PLCC, SMD01 pce
XIC 10 53.60.0244 44p PLCC, SMD01 pce
XIC 10 53.60.0244 44p PLCC, SMD01 pce
Y 1 89.60.1014 19.200MHz SMD Quartz01 pce
Y 2 89.60.1008 3.6864MHz SMD Quartz 3.6864 MHz01 pce
Y 3 89.60.1004 22.1184MHz SMD Quartz01 pce
Y 4 89.60.1004 22.1184MHz SMD Quartz01 pce
End of List
Comments:
[22] 04.06.2008 PG value changes: R394 1k => 3k3; R422 27k => 39k
Date printed: 06.06.2008
