Technical Specifications
General
Level specs, digital, in dBFS: dB, referenced to full modulation (dBFS, dB Full
Scale)
Level specs, analogue, in dBu: 0 dB Ø 0.775 Vrms
Sampling rate: 48 kHz ±50 ppm (internally synchronized)
Headroom adjustable: 0 to 20 dB
Default setting: 9 dB
Output Level: 15 dBu @ 0 dBFS
All input faders set to their 0 dB position. External analogue sources:
source impedance < 200 Ω. Frequency range: 20 Hz to 20 kHz, if not
stated otherwise.
Microphone inputs
Input sensitivity: –60 dBu…26 dBu for 0 dBFS
Gain setting: in steps of 1dB
Frequency response: 30 Hz…20 kHz, –0.3 dB
High pass lter (12 dB/Octave): 75 Hz
Input impedance: 1.8 kOhm
Insert level (for 0 dBFS) +15 dBu
Dynamic range: 107 dB
THD+N (30 Hz … 20 kHz, –30 dBFS): –100 dBFS
THD+N (1 kHz, –1 dBFS): –95 dBFS
Equivalent input noise (200 Ω Ri, max gain): –124 dBu
Crosstalk, 1 kHz: –100 dB
Phantom power, switchable: 48 V
Line level inputs
Level (for full scale) 15 or 24 dBu xed (jumper), or 7...26 dBu adjustable
Input impedance min. 10 kΩ
Frequency response 20 Hz...20 kHz –0.2 dB
THD & N (35 Hz … 20 kHz, –30 dBFS), input level xed max. –108 dBFS
THD & N (1 kHz, –1 dBFS), input level xed max. –97 dBFS
Crosstalk 1 kHz max. –110 dB
Digital inputs/outputs
Input/Output impedance 110 Ω
Output level (into 110 Ω) 5V
Input Sampling rate with SRC 32 … 108 kHz
Analogue outputs
Level (for full scale) 15 or 24 dBu xed (jumper), or 7 … 26 dBu adjustable
Output Impedance 50 Ω
min. Load at +24 dBu 600 Ω
Frequency response 20 Hz … 20 kHz –0.2 dB
THD & N (20 Hz … 20 kHz, –30 dBFS), input level xed max. –104 dBFS
THD & N (1 kHz, –1 dBFS), input level xed max. –93 dBFS
Crosstalk 1 kHz max. –110 dBFS
Equalizer
4 Band, each band sweepable 20 Hz…20 kHz: ±18 dB
Q-factor 0.27 … 8.7
Dynamics
Dynamic level 0 dB … +24 dB
Dynamics ON/OFF
Limiter
Threshold -39 … + 9dB
Attack time 0.2 msec … 1 msec
Release time 10 msec … 10 sec
Compressor
Threshold -87 … +9 dB
Ratio 20:1 … 1:1
Attack time 0.2 msec … 20 msec
Release time 10 msec … 10 sec
Expander
Threshold -87 … +9 dB
Ratio 20:1 … 1:1
Attack time 0.2 msec … 1 msec
Release time 10 msec … 10 sec
Noise Gate
Threshold -87 … +9 dB
Attenuation -48 dB … 0 dB
Attack time 0.2 msec … 1 msec
Release time 10 msec … 10 sec
De-esser
Frequency range 4 kHz … 14 kHz
Q-factor 0.27 … 8.7
Threshold -87 dB … + 8 dB Auto Mode
Ratio 20:1 … 1:1
Power supply
Mains voltage: 100 to 240 V, 50/60 Hz (auto-ranging)
Power consumption Desk: typ. System 100 W
Weight
OnAir 2500 12 fader 17 kg
Note:
We reserve the right to change specifications as technological progress
may warrant. Data subject to change without notice
