Studer OnAir 2500 - Toslink if Pcb 1.943.449.00

Part No. Qty. Type/Val. DescriptionPos.Idx. Part No. Qty. Type/Val. DescriptionPos.Idx.
OnAir 2500
Page: 1 of 1
TOSLINK IF PCB 1.943.449.00 ( 1)
C 1 59.60.3337 100n CER 50V, 10%, X7R, 080501 pce
C 2 59.60.3337 100n CER 50V, 10%, X7R, 080501 pce
C 3 59.68.0317 220u EL 35V, 10 *10.7 lowESR01 pce
C 4 59.60.3337 100n CER 50V, 10%, X7R, 080501 pce
C 5 59.60.3337 100n CER 50V, 10%, X7R, 080501 pce
C 6 59.60.3325 10n CER 50V, 10%, X7R, 080501 pce
C 7 59.68.0275 470u EL 16V, 10 *10.7 lowESR01 pce
C 8 59.60.3337 100n CER 50V, 10%, X7R, 080501 pce
C 9 59.60.3337 100n CER 50V, 10%, X7R, 080501 pce
C 10 59.60.3337 100n CER 50V, 10%, X7R, 080501 pce
D 1 50.60.8102 SS34 3A 40V Schottky01 pce
IC 1 50.61.2005 LM2673ADJ Step down converter01 pce
IC 36 89.10.0132 TOTX196B(F) Toslink Transmitter11 pce
IC 37 89.10.0131 TORX194(F) Toslink Receiver11 pce
J 1 54.11.0136 2*3p Pin 0.63*0.63, RM2.5401 pce
L 1 62.60.0518 47uH SMD 2.5A01 pce
MP 1 1.943.449.11 TOSLINK INTERFACE PCB01 pce
MP 2 1.943.449.10 NR. ETIKETTE 5x2001 pce
MP 3 43.01.0108 Label ESE-Warnschild01 pce
MP 4 21.53.9356 M3*10 Z-Schraube Inbus-Ripp Zn bl ch02 pcs
MP 5 1.943.449.02 TOSLINKHALTER01 pce
MP 6 54.01.0021 Jumper 0.63*0.63mm, Au02 pcs
MP 7 1.943.449.93 LL Desk Illumination01 pce
P 1 54.12.0702 2p Stecker gerade PCB01 pce
R 1 57.60.1392 3k9 MF, 1%, 0204, E2401 pce
R 2 57.60.1153 15k MF, 1%, 0204, E2401 pce
R 3 57.60.1152 1k5 MF, 1%, 0204, E2401 pce
R 4 57.60.1472 4k7 MF, 1%, 0204, E2401 pce
R 5 57.60.1103 10k MF, 1%, 0204, E2401 pce
R 6 57.60.1273 27k MF, 1%, 0204, E2401 pce
R 7 57.60.1152 1k5 MF, 1%, 0204, E2401 pce
R 8 57.60.1560 56R MF, 1%, 0204, E2401 pce
R 9 57.60.1822 8k2 MF, 1%, 0204, E2401 pce
End of List
Comments:
(01) 18.08.04 fault corr: IC2,89.10.0131->IC36,89.10.0132
IC3,89.10.0111->IC37,89.10.0131
Date printed: 06.06.2008
