Studer OnAir 2500 Manual

Part No. Qty. Type/Val. DescriptionPos.Idx. Part No. Qty. Type/Val. DescriptionPos.Idx.
OnAir 2500
Page: 4 of 4
DSP PCB 1.943.632.22 ( 0)
R 377 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 378 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 380 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 382 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 383 57.69.1000 0R0 060301 pce
R 384 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 387 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 388 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 390 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 391 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 392 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 393 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 394 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 395 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 397 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 398 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 404 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 405 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 406 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 407 57.61.1221 220R MF, 1%, Chip 0603, E1201 pce
R 408 57.61.1221 220R MF, 1%, Chip 0603, E1201 pce
R 410 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 411 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 413 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 414 57.61.1221 220R MF, 1%, Chip 0603, E1201 pce
R 415 57.61.1221 220R MF, 1%, Chip 0603, E1201 pce
R 416 57.61.1221 220R MF, 1%, Chip 0603, E1201 pce
R 417 57.61.1473 47k MF, 1%, Chip 0603, E1201 pce
R 420 57.61.1682 6k8 MF, 1%, Chip 0603, E1201 pce
R 422 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 423 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 424 57.61.1221 220R MF, 1%, Chip 0603, E1201 pce
R 425 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 426 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 427 57.61.1221 220R MF, 1%, Chip 0603, E1201 pce
R 428 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 429 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 433 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 434 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 436 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 439 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 440 57.61.1101 100R MF, 1%, Chip 0603, E1201 pce
R 441 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 442 57.61.1123 12k MF, 1%, Chip 0603, E1201 pce
R 443 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 444 57.61.1472 4k7 MF, 1%, Chip 0603, E1201 pce
R 445 57.61.1473 47k MF, 1%, Chip 0603, E1201 pce
R 447 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 451 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 452 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 453 57.61.1103 10k MF, 1%, Chip 0603, E12
01 pce
R 454 57.61.1331 330R MF, 1%, Chip 0603, E1201 pce
R 455 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 462 57.61.1332 3k3 MF, 1%, Chip 0603, E1201 pce
R 466 57.61.1332 3k3 MF, 1%, Chip 0603, E1201 pce
R 467 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 469 57.61.1332 3k3 MF, 1%, Chip 0603, E1201 pce
R 470 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 473 57.61.1332 3k3 MF, 1%, Chip 0603, E1201 pce
R 474 57.69.1000 0R0 060301 pce
R 475 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 480 57.61.1332 3k3 MF, 1%, Chip 0603, E1201 pce
R 481 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 482 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 485 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 486 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 487 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 488 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 489 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 490 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 491 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 496 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 497 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 498 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 507 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 508 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 509 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 510 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 511 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 512 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 513 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 517 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 518 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 519 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 520 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 527 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 528 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 529 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 530 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 531 not used 10k MF, 1%, Chip 0603, E1201 pce
R 532 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 534 57.61.1331 330R MF, 1%, Chip 0603, E1201 pce
R 543 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 544 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 545 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 547 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 548 57.61.1332 3k3 MF, 1%, Chip 0603, E1201 pce
R 553 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 554 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 555 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 566 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 567 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 568 57.61.1332 3k3 MF, 1%, Chip 0603, E1201 pce
R 569 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 570 57.61.1100 10R MF, 1%, Chip 0603, E1201 pce
R 573 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 575 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 576 57.61.1473 47k MF, 1%, Chip 0603, E1201 pce
R 577 57.61.1105 1M0 MF, 1%, Chip 0603, E1201 pce
R 578 57.69.1000 0R0 060301 pce
R 579 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 582 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 585 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 586 57.61.1123 12k MF, 1%, Chip 0603, E1201 pce
R 592 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 596 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 597 57.61.1223 22k MF, 1%, Chip 0603, E1201 pce
R 598 57.61.1123 12k MF, 1%, Chip 0603, E1201 pce
R 599 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 600 not used 1k0 MF, 1%, Chip 0603, E1201 pce
R 601 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 604 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 605 not used 10k MF, 1%, Chip 0603, E1201 pce
R 609 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 611 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 612 57.61.1330 33R MF, 1%, Chip 0603, E1201 pce
R 613 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 615 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 617 57.69.1000 0R0 060301 pce
R 618 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 619 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 620 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 624 57.61.1471 470R MF, 1%, Chip 0603, E1201 pce
R 627 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 628 not used 0R0 060301 pce
R 629 57.69.1000 0R0 060301 pce
R 630 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 631 not used 0R0 060301 pce
S 1 55.60.0201 1*s SMD Tactswitch01 pce
S 2 55.60.0104 4p SMD DIL-Switch01 pce
S 4 55.60.0201 1*s SMD Tactswitch01 pce
TP 8 not used 1p PCB-Flachst 2.8*0.8, gerade01 pce
TP 9 not used 1p PCB-Flachst 2.8*0.8, gerade01 pce
TP 10 not used 1p PCB-Flachst 2.8*0.8, gerade01 pce
TP 11 not used 1p PCB-Flachst 2.8*0.8, gerade01 pce
TP 13 not used 1p PCB-Flachst 2.8*0.8, gerade01 pce
TP 14 not used 1p PCB-Flachst 2.8*0.8, gerade01 pce
TP 15 not used 1p PCB-Flachst 2.8*0.8, gerade01 pce
TP 16 not used 1p PCB-Flachst 2.8*0.8, gerade01 pce
XIC 19 53.60.0232 32p PLCC, SMD01 pce
Y 2 89.60.1013 20.000MHz SMD Quartz01 pce
End of List
Comments:
[22] 29.05.08 PG
Date printed: 06.06.2008
