Part No. Qty. Type/Val. DescriptionPos.Idx. Part No. Qty. Type/Val. DescriptionPos.Idx.
OnAir 2500
Page: 2 of 2
Monitoring Front PCB 1.943.441.00 ( 0)
R 25 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 26 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 27 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 28 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 29 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 30 57.60.1103 10k MF, 1%, 0204, E2401 pce
R 31 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 32 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 33 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 34 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 35 57.60.1103 10k MF, 1%, 0204, E2401 pce
R 36 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 37 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 38 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 39 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 40 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 41 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 42 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 43 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 44 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 45 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 46 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 47 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 48 57.60.1271 270R MF, 1%, 0204, E2401 pce
R 49 57.60.1103 10k MF, 1%, 0204, E2401 pce
R 50 57.60.1472 4k7 MF, 1%, 0204, E2401 pce
R 51 57.60.1472 4k7 MF, 1%, 0204, E2401 pce
R 52 57.60.1271 270R MF, 1%, 0204, E2401 pce
R 53 57.60.1220 22R MF, 1%, 0204, E2401 pce
R 54 57.60.1104 100k MF, 1%, 0204, E2401 pce
R 55 57.60.1104 100k MF, 1%, 0204, E2401 pce
R 56 57.60.1102 1k0 MF, 1%, 0204, E2401 pce
R 57 57.60.1102 1k0 MF, 1%, 0204, E2401 pce
R 58 57.60.1471 470R MF, 1%, 0204, E2401 pce
R 59 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 60 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 61 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 62 57.60.1221 220R MF, 1%, 0204, E2401 pce
R 63 57.60.1102 1k0 MF, 1%, 0204, E2401 pce
R 64 57.60.1471 470R MF, 1%, 0204, E2401 pce
R 65 57.60.1471 470R MF, 1%, 0204, E2401 pce
R 66 57.60.1271 270R MF, 1%, 0204, E2401 pce
R 67 57.60.1471 470R MF, 1%, 0204, E2401 pce
R 68 57.60.1102 1k0 MF, 1%, 0204, E2401 pce
R 69 57.60.1271 270R MF, 1%, 0204, E2401 pce
R 70 57.60.1681 680R MF, 1%, 0204, E2401 pce
R 71 57.60.1151 150R MF, 1%, 0204, E2401 pce
R 72 57.60.1681 680R MF, 1%, 0204, E2401 pce
R 73 57.60.1681 680R MF, 1%, 0204, E2401 pce
R 74 57.60.1681 680R MF, 1%, 0204, E2401 pce
R 75 57.60.1103 10k MF, 1%, 0204, E24
01 pce
R 76 57.60.1103 10k MF, 1%, 0204, E2401 pce
R 77 57.60.1471 470R MF, 1%, 0204, E2401 pce
R 78 57.60.1220 22R MF, 1%, 0204, E2401 pce
R 79 57.60.1271 270R MF, 1%, 0204, E2401 pce
R 80 57.60.1220 22R MF, 1%, 0204, E2401 pce
R 81 57.60.1471 470R MF, 1%, 0204, E2401 pce
R 82 57.60.1151 150R MF, 1%, 0204, E2401 pce
R 83 57.60.1271 270R MF, 1%, 0204, E2401 pce
R 84 57.60.1472 4k7 MF, 1%, 0204, E2401 pce
R 85 57.60.1472 4k7 MF, 1%, 0204, E2401 pce
R 86 57.60.1271 270R MF, 1%, 0204, E2401 pce
R 87 57.60.1271 270R MF, 1%, 0204, E2401 pce
R 88 57.60.1471 470R MF, 1%, 0204, E2401 pce
R 89 57.60.1271 270R MF, 1%, 0204, E2401 pce
R 90 57.60.1104 100k MF, 1%, 0204, E2401 pce
R 91 57.60.1104 100k MF, 1%, 0204, E2401 pce
R 92 57.60.1151 150R MF, 1%, 0204, E2401 pce
R 93 57.60.1151 150R MF, 1%, 0204, E2401 pce
R 94 57.60.1103 10k MF, 1%, 0204, E2401 pce
R 95 57.60.1271 270R MF, 1%, 0204, E2401 pce
R 96 57.60.1103 10k MF, 1%, 0204, E2401 pce
R 97 57.60.1103 10k MF, 1%, 0204, E2401 pce
RA 1 58.20.7102 10k Pot, lin01 pce
RA 2 58.20.7102 10k Pot, lin01 pce
S 38 55.12.1304 N=18 Encoder01 pce
S 48 55.12.1304 N=18 Encoder01 pce
XIC 7 53.03.0218 1p single-in-line0 26 pcs
End of List
