Studer OnAir 2500 Manual

Part No. Qty. Type/Val. DescriptionPos.Idx. Part No. Qty. Type/Val. DescriptionPos.Idx.
OnAir 2500
Page: 4 of 4
Monitoring Audio Ctrl PCB (fixframe) 1.943.448.23 ( 0)
R 287 57.60.1273 27k MF, 1%, 0204, E2401 pce
R 288 57.60.1561 560R MF, 1%, 0204, E2401 pce
R 289 57.60.1561 560R MF, 1%, 0204, E2401 pce
R 290 57.60.1273 27k MF, 1%, 0204, E2401 pce
R 291 57.60.1102 1k0 MF, 1%, 0204, E2401 pce
R 292 57.60.1561 560R MF, 1%, 0204, E2401 pce
R 293 57.60.1105 1M0 MF, 1%, 0204, E2401 pce
R 294 57.60.1472 4k7 MF, 1%, 0204, E2401 pce
R 295 57.60.1392 3k9 MF, 1%, 0204, E2401 pce
R 296 57.60.1103 10k MF, 1%, 0204, E2401 pce
R 297 57.60.1105 1M0 MF, 1%, 0204, E2401 pce
R 298 57.60.1392 3k9 MF, 1%, 0204, E2401 pce
R 299 57.60.1103 10k MF, 1%, 0204, E2401 pce
R 300 57.60.1102 1k0 MF, 1%, 0204, E2401 pce
R 301 57.60.1392 3k9 MF, 1%, 0204, E2401 pce
R 302 57.60.1222 2k2 MF, 1%, 0204, E2401 pce
R 303 57.60.1392 3k9 MF, 1%, 0204, E2401 pce
R 304 57.60.1152 1k5 MF, 1%, 0204, E2401 pce
R 305 57.60.1105 1M0 MF, 1%, 0204, E2401 pce
R 306 57.60.1102 1k0 MF, 1%, 0204, E2401 pce
R 307 57.60.1392 3k9 MF, 1%, 0204, E2401 pce
R 308 57.60.1392 3k9 MF, 1%, 0204, E2401 pce
R 309 57.60.1103 10k MF, 1%, 0204, E2401 pce
R 310 57.60.1105 1M0 MF, 1%, 0204, E2401 pce
R 311 57.60.1560 56R MF, 1%, 0204, E2401 pce
R 312 57.60.1102 1k0 MF, 1%, 0204, E2401 pce
R 313 57.60.1102 1k0 MF, 1%, 0204, E2401 pce
R 314 57.60.1102 1k0 MF, 1%, 0204, E2401 pce
RA 1 not used 1k0 10%, 0.5W, Cermet01 pce
S 1 55.60.0201 1*s SMD Tactswitch01 pce
XIC 14 53.03.2244 44p PLCC-Socket01 pce
XIC 25 53.03.0166 8p DIL-socket 0.3"01 pce
XIC 35 53.03.2220 20p PLCC-Socket01 pce
Y 1 89.60.1004 22.1184MHz SMD Quartz01 pce
Y 2 89.60.1003 12.000MHz SMD Quartz01 pce
End of List
Comments:
[23] 22.01.07 ZT
Note: Instead of IC36, IC37 -> P9, P10 shall be equipped
An Stelle von IC36, IC37 werden P9, P10 bestückt
Date printed: 06.06.2008
