Studer OnAir 2500 Manual

Part No. Qty. Type/Val. DescriptionPos.Idx. Part No. Qty. Type/Val. DescriptionPos.Idx.
OnAir 2500
Page: 3 of 3
Central Front PCB 1.943.621.21 ( 0)
R 107 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 108 57.69.1000 0R0 060301 pce
R 109 57.69.1000 0R0 060301 pce
R 110 57.61.1681 680R MF, 1%, Chip 0603, E1201 pce
R 111 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 112 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 113 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 114 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 115 57.61.1681 680R MF, 1%, Chip 0603, E1201 pce
R 116 57.61.1681 680R MF, 1%, Chip 0603, E1201 pce
R 117 57.61.1681 680R MF, 1%, Chip 0603, E1201 pce
R 118 57.61.1560 56R MF, 1%, Chip 0603, E1201 pce
R 119 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 120 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 121 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 122 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 123 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 124 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 125 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 126 57.61.1560 56R MF, 1%, Chip 0603, E1201 pce
R 127 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 128 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 129 57.61.1332 3k3 MF, 1%, Chip 0603, E1201 pce
R 130 57.61.1332 3k3 MF, 1%, Chip 0603, E1201 pce
R 131 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 132 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 133 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 134 57.61.1104 100k MF, 1%, Chip 0603, E1201 pce
R 135 57.61.1105 1M0 MF, 1%, Chip 0603, E1201 pce
R 136 57.61.1104 100k MF, 1%, Chip 0603, E1201 pce
R 137 57.61.1472 4k7 MF, 1%, Chip 0603, E1201 pce
R 138 57.61.1472 4k7 MF, 1%, Chip 0603, E1201 pce
R 139 57.61.1104 100k MF, 1%, Chip 0603, E1201 pce
R 140 57.61.1104 100k MF, 1%, Chip 0603, E1201 pce
R 141 57.61.1104 100k MF, 1%, Chip 0603, E1201 pce
R 142 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 143 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 144 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 145 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 146 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 147 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 148 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 149 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 150 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 151 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 152 57.61.1104 100k MF, 1%, Chip 0603, E1201 pce
R 153 57.61.1472 4k7 MF, 1%, Chip 0603, E1201 pce
R 154 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 155 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 156 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 157 57.61.1151 150R MF, 1%, Chip 0603, E12
01 pce
R 158 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 159 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 160 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 161 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 162 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 163 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 164 57.61.1472 4k7 MF, 1%, Chip 0603, E1201 pce
R 165 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 166 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 167 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 168 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 169 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 170 57.61.1472 4k7 MF, 1%, Chip 0603, E1201 pce
R 171 57.61.1472 4k7 MF, 1%, Chip 0603, E1201 pce
R 172 57.61.1104 100k MF, 1%, Chip 0603, E1201 pce
R 173 57.61.1104 100k MF, 1%, Chip 0603, E1201 pce
R 174 57.61.1104 100k MF, 1%, Chip 0603, E1201 pce
R 175 57.61.1104 100k MF, 1%, Chip 0603, E1201 pce
R 176 57.61.1472 4k7 MF, 1%, Chip 0603, E1201 pce
R 177 57.61.1472 4k7 MF, 1%, Chip 0603, E1201 pce
R 178 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 179 57.61.1105 1M0 MF, 1%, Chip 0603, E1201 pce
R 180 57.61.1332 3k3 MF, 1%, Chip 0603, E1201 pce
R 181 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 182 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 183 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 184 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 185 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 186 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 187 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 188 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 189 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 190 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 191 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 192 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 193 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 194 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 195 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 196 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 197 57.61.1151 150R MF, 1%, Chip 0603, E1201 pce
R 198 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 199 not used 56R MF, 1%, Chip 0603, E1201 pce
R 200 not used 56R MF, 1%, Chip 0603, E1201 pce
R 201 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 202 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 203 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 204 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 205 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 206 57.69.1000 0R0 060301 pce
R 207 57.69.1000 0R0 060301 pce
R 208 57.69.1000 0R0 060301 pce
R 209 57.61.1105 1M0 MF, 1%, Chip 0603, E1201 pce
R 210 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 211 57.61.1102 1k0 MF, 1%, Chip 0603, E1201 pce
R 212 57.69.1000 0R0 060301 pce
R 213 57.69.1000 0R0 060301 pce
R 301 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 304 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 307 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 311 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 314 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
R 317 57.61.1103 10k MF, 1%, Chip 0603, E1201 pce
S 1 55.60.0201 1*s SMD Tactswitch01 pce
S 2 55.12.1304 N=18 Encoder01 pce
S 3 55.12.1304 N=18 Encoder01 pce
S 4 55.12.1304 N=18 Encoder01 pce
S 43 55.12.1304 N=18 Encoder01 pce
XIC 1 not used 8p DIL-socket 0.3"01 pce
Y 1 89.60.1003 12.000MHz SMD Quartz01 pce
Y 2 89.60.1003 12.000MHz SMD Quartz01 pce
End of List
Comments:
[21] 12.03.2008 ZT release
Date printed: 06.06.2008
